CONVEYOR EQUIPMENT
Z Type Bucket Elevator

Z-Type Bucket Elevator is the most common lifting conveying equipment. it is mainly consist of Movement part (Bucket and Rubber belt or Chain), Upper part with Transmission Drum, Down parts with Tension Drum, Middle Cabinet, Drive device and son.

Category:CONVEYOR EQUIPMENT
Online Service
LEAVE MESSAGE
*Introduce Yourself
*Phone Number
*Message
Z Type Bucket Elevator
Z Type Bucket Elevator

Z-Type Bucket Elevator is the most common lifting conveying equipment. it is mainly consist of Movement part (Bucket and Rubber belt or Chain), Upper part with Transmission Drum, Down parts with Tension Drum, Middle Cabinet, Drive device and son.

Feature & Benefits

1. 304 Stainless steel material for fuselage, sturdy and durable.

2. The bucket can use ABS or stainless steel materials.

3. Fully enclosed structure, no dust, material without breakage.

4. The bucket elevators allow for controlled discharge at one or more locations and can easily interface with various types of feeding devices.

5. Electromagnetic vibration feeder feed material is possible.

6. Multiple discharges can be pneumatically controlled.

7. The whole process of feeding, conveying and unloading has no damage to the material itself, which can be greatly bring down the reject rate.

8. Conveying height up to 20 meters.

9. According to the requirements of users (different materials, delivery capacity, delivery height) for the design and production.

1585722145462224

Structure Diagram

未标题-1

Application

Z-Type Bucket Elevator is used mainly to convey the solid food which is very well suited for free flowing products in the food, agriculture, pharmaceutical, cosmetic, chemical industry, such as candy, chips, peanut, nut, frozen food etc.

未标题-1

Technical Parameter

Bucket Volume

1.8L

3.8L

6.5L

Bucket Material

ABS.PP or SUS304

ABS.PP or SUS304

ABS.PP or SUS304

Discharge outlet

Single

Single or multiple

Single or multiple

Frame material

Mid steel or SUS304

Mid steel or SUS304

Mid steel or SUS304

Maximal Output

6 CBM/H

9 CBM/H

15 CBM/H

Available Voltage

AC single P 110V/220V or 3P 220V/240V/380V/415V/440V/660V

Power

0

0.75kw

1.5KW/2.2kw

2.2KW/3.7kw

Real Case

222

FAQ

Q1: What's material to elevator?

 Like: Solid, Granule, Flake, Powder or liquid.

Q2: What is the particle size?

 EM: Mesh/Micron/mm

Q3: What is the lifting height?

EM: Lifting height: 300mm

Q4: What is the capacity per hour?

EM: 50kg/h

Q5: What's the material of machine?

SUS 304 stainless steel, or Carbon steel or sus 304 for contacting parts.

Q6: What's usually power ______Voltage ______Frequency in your city?

Various power voltage: 110V 200V 240V 380V 415V 450V 550V
Power Frequency: 50HZ 60HZ or Single phase electricity

Q7: How do you ensure the quality of your products?

A: Generally, our equipments are the most durable type in the industry, this is also the feature of the label impression of  the most of our customers at home or abroad.

Q8: How do your after-sale service work if the product got damaged?

A: During the maintenance period, our general after-sale service is changing the damaged parts for the customer. Normally, we will provide on-site guidance.
